Ring light source angle coverage, forming a complete application system
Can be used in conjunction with diffuse reflective panels to provide uniform light.
Multi-angle irradiation, to solve the shadow of diagonal irradiation
Character Recognition
Two-dimensional code reading
Plastic Container Appearance Inspection
|
XL |
- |
AR |
- |
20 |
90 |
- |
R |
|
① |
|
② |
|
③ |
④ |
|
⑤ |
|
① |
Brand XISPEK LIGHING |
|
② |
AR Ring Light Series |
|
③ |
Outer diameter of light source |
|
④ |
Light source angle (15, 30, 45, 60, 75, 90) special angle can be customized |
|
⑤ |
Light source color (R is red, B is blue, W is white, ⑤ light source color) |
|
Model |
Voltage/Power |
Product Size |
|||
|
R |
B G W |
Outer diameter mm |
Inner Diameter mm |
Angle |
|
|
XL-AR-9290 |
24V/5.2W |
24V/7.5W |
92 |
40 |
90° |
|
XL-AR-18090 |
24V/25.0W |
24V/32.0W |
180 |
60 |
90° |
|
XL-AR-3475 |
24V/1.1W |
24V/1.5W |
34 |
10 |
75° |
|
XL-AR- 10375 |
24V/7.7W |
24V/11.0W |
103 |
48 |
75° |
|
XL-AR-4660 |
24V/1.5W |
24V/2.1W |
46 |
20 |
60° |
|
XL-AR-9260 |
24V/5.8W |
24V/8.4W |
92 |
48 |
60° |
|
XL-AR-5445 |
24V/1.7W |
24V/2.3W |
54 |
25 |
45° |
|
XL-AR-9245 |
24V/5.5W |
24V/8.1W |
92 |
52 |
45° |
|
XL-AR-7430 |
24V/3.1W |
24V/4.8W |
74 |
41 |
30° |
|
XL-AR-20230 |
24V/12.4W |
24V/15.5W |
202 |
167 |
30° |
|
XL-AR-7415 |
24V/4.0W |
24V/5.0W |
74 |
38 |
15° |
